DESIGN GUIDELINES

Stainless Steel (C645)

General guidelines

Sample 3D design of a part in aluminum on a computer window

Technical specifications

Maximum part dimensions

250 x 250 x 280 mm

Standard accuracy

In accordance with:

    • DCTG 8 of DIN EN ISO 8062-3: 2008-09 for dimensions between 30 and 400 mm
    • DCTG 6 of DIN EN ISO 8062-3: 2008-09 for dimensions below 30 mm
    • DIN ISO 2768 -1 g (rough) for dimensions between 3 and 400 mm
Layer thickness

0.04 mm

Minimum wall thickness

Standard: 1 mm, Performance: 0.5 mm

Minimum detail size

0.5 mm

Interlocking or moving parts

No

Internal channels

Yes

Surface structure

Rough surface
